JSV-89C4 (DC12V,LVDS)





Specification

CPU Intel® 8-9th Generation CorePentium

/ Celeron Desktop CPU, LGA1151

RAM Support DDR4-2400/2666MHz, 2 * non-ECC SO-DIMM Slot, Up to 32GB

Display 2 * HDMI (upright 90° TYPE-A): max resolution up to 4096x2160@24Hz

1 * DP++ (upright 90° Connector): DP++ max resolution up to 4096x2304

1 * LVDS/EDP (Header): LVDS up to 1920x1200@60Hz (default)

Ethernet RJ45_1: 1 * Realtek GBE LAN Chip (RJ45, 10/100/1000 Mbps)

LAN1: 1 * Realtek GBE LAN Chip (RJ45, 10/100/1000 Mbps)

BIOS AMI UEFI BIOS (Support Watchdog Timer)

Storage 2 * SATA3.0 7P Connector (with 2 * SATA Power Header)

Support M.2 Key-M 2242/2280 SATA/ Support M.2 Key-B 2242/2280 SATA

Audio Realtek ALC662 5.1 Channel HDA Codec,

Expansion 1 * PCI-E 4x Slot (PCIe 3.0) 1 * M.2 (NGFF) key-E Slot (PCIE+USB, WIFI+BT, 2230)

Other Ports 8 * GPIO1 * Port80 Debug Header1 * CPU FAN Header2 x LAN1 * System FAN Header1 x DC-IN1 * AT or ATX Select Jumper1 * Front Panel Header (PWR-ON+RST+HD LED+PWR LED)2 * RS232 (COM1/2, Full lanes, Header)2 * RS232/485 (COM3/4, Full lanes, Header)

Power 12V DC in

Mechanical&Environmental Mini-ITX170mm x 170mm

Operating: 0~60℃Storage: -20~75℃​

OS Windows 10, Linux
